• Year
  • 1938
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 255771

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 472 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 100; 115; 130; 150; 220; 250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 865 - LMT L.M.T., Le Matériel
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 570 x 340 x 310 mm / 22.4 x 13.4 x 12.2 inch
  • Notes
  • Modèle pour courant alternatif 25 périodes. Voir aussi modèle 86 (50 périodes).

  • Author
  • Model page created by Mark Hippenstiel. See "Data change" for further contributors.
