Arena 83071; Loewe-Opta; (ID = 301406) Television
Loewe-Opta;: Arena 83071 [Television] ID = 301406 517x391
Select picture or schematic to display from thumbnails on the right and click for download.
For model Arena 83071, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1966–1968 Category: Television Receiver (TV) or Monitor
Valves / Tubes 9: PCL86 PCL200 PCH200 PCF802 PL500 PY88 DY86 PCL85 A59-12W or A59-11W
Semiconductors (the count is only for transistors) 10:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Arena 83071 - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 740 x 500 x 255 mm / 29.1 x 19.7 x 10 inch
Notes VHF/UHF. Technische Daten wie Atlanta 83062, jedoch anderes Gehäuse.
Net weight (2.2 lb = 1 kg) 28 kg / 61 lb 10.8 oz (61.674 lb)
Price in first year of sale 528.00 DM
External source of data erb
Source of data Handbuch VDRG 1966/1967


All listed radios etc. from Loewe-(Opta); Deutschland
Here you find 1564 models, 1292 with images and 1146 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
