For model ST208 Electronic 54270, Loewe-(Opta); Deutschland:
Q: Loewe-Opta Service

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1974–1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 20:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: ST208 Electronic 54270 - Loewe-Opta; Deutschland
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 510 x 110 x 230 mm / 20.1 x 4.3 x 9.1 inch
Notes ICs: 2.
Stereo-Steuergerät; NF-Verstärker mit 2 Endstufen je 7 W (Sinus); zwei LS-Boxen LO18 (180×250×120 mm, 1,9 kg) sind im Lieferumfang.
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
External source of data Erb
Source of data Katalog RFP 1974
Mentioned in Handbuch VDRG 1975/1976
