Entzerrer-Vorverstärker 62 979

Entzerrer-Vorverstärker 62 979; Loewe-Opta; (ID = 334484) Ampl/Mixer

Entzerrer-Vorverstärker 62 979; Loewe-Opta; (ID = 1010490) Ampl/Mixer

Entzerrer-Vorverstärker 62 979; Loewe-Opta; (ID = 1010491) Ampl/Mixer
Entzerrer-Vorverstärker 62 979; Loewe-Opta; (ID = 447607) Ampl/Mixer
Use red slider bar for more.
Entzerrer-Vorverstärker 62 979; Loewe-Opta; (ID = 447607) Ampl/Mixer
Loewe-Opta;: Entzerrer-Vorverstärker 62 979 [Ampl/Mixer] ID = 447607 473x266
Select picture or schematic to display from thumbnails on the right and click for download.
For model Entzerrer-Vorverstärker 62 979, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1965–1968 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 4: AC151 AC151 AC151 AC151
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Entzerrer-Vorverstärker 62 979 - Loewe-Opta; Deutschland
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 123 x 35 x 86 mm / 4.8 x 1.4 x 3.4 inch
External source of data erb
Source of data Handbuch VDRG 1965/1966
