F815

F815; Loewe-Opta; (ID = 626518) Television

F815; Loewe-Opta; (ID = 626519) Television

F815; Loewe-Opta; (ID = 626520) Television
Use red slider bar for more.
F815; Loewe-Opta; (ID = 626518) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1969/1970 Category: Television Receiver (TV) or Monitor
Valves / Tubes A50-120W
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: F815 - Loewe-Opta; Deutschland
Material Wooden case
Dimensions (WHD) 595 x 420 x 310 mm / 23.4 x 16.5 x 12.2 inch
Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
External source of data erb
Source of data Handbuch VDRG 1969/1970
