Iris 670

Iris 670; Loewe-Opta; (ID = 584398) Television

Iris 670; Loewe-Opta; (ID = 584399) Television

Iris 670; Loewe-Opta; (ID = 584400) Television

Iris 670; Loewe-Opta; (ID = 584401) Television

Iris 670; Loewe-Opta; (ID = 584402) Television

Iris 670; Loewe-Opta; (ID = 584403) Television

Iris 670; Loewe-Opta; (ID = 584404) Television

Iris 670; Loewe-Opta; (ID = 584406) Television

Iris 670; Loewe-Opta; (ID = 584407) Television

Iris 670; Loewe-Opta; (ID = 584408) Television
Iris 670; Loewe-Opta; (ID = 813056) Television Iris 670; Loewe-Opta; (ID = 606991) Television
Use red slider bar for more.
Iris 670; Loewe-Opta; (ID = 813056) Television
Loewe-Opta;: Iris 670 [Television] ID = 813056 396x325
Select picture or schematic to display from thumbnails on the right and click for download.
For model Iris 670, Loewe-(Opta); Deutschland:
Quelle: Handbuch für Fernsehen 1960-61 Walter Kluxen Hamburg

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1960/1961 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: AW43-88
Main principle Super-Heterodyne (Super in general); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Iris 670 - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 420 x 350 mm / 20.1 x 16.5 x 13.8 inch
Notes VHF; UHF gegen Mehrpreis (92,- DM), dann 17 Röhren. UHF-Tuner NSF Type 114 oder Valvo AT6321 nachrüstbar.
Net weight (2.2 lb = 1 kg) 23 kg / 50 lb 10.6 oz (50.661 lb)
Price in first year of sale 668.00 DM
Collectors' prices
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
