Netzautomatik T92 53212

Netzautomatik T92 53212; Loewe-Opta; (ID = 340639) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 340640) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 340641) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 340642) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 340644) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 340643) Radio

Netzautomatik T92 53212; Loewe-Opta; (ID = 1800467) Radio
Netzautomatik T92 53212; Loewe-Opta; (ID = 57337) Radio Netzautomatik T92 53212; Loewe-Opta; (ID = 57338) Radio
Netzautomatik T92 53212; Loewe-Opta; (ID = 57339) Radio Netzautomatik T92 53212; Loewe-Opta; (ID = 57341) Radio
Netzautomatik T92 53212; Loewe-Opta; (ID = 1755686) Radio
Use red slider bar for more.
Netzautomatik T92 53212; Loewe-Opta; (ID = 57337) Radio
Loewe-Opta;: Netzautomatik T92 53212 [Radio] ID = 57337 933x589
Select picture or schematic to display from thumbnails on the right and click for download.
For model Netzautomatik T92 53212, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1973/1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 4: BF314 BF254 TBA570 AA119 AA119 AC187 AC188 Si-Br-Gl
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220; (4 × 1,5) Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Netzautomatik T92 53212 - Loewe-Opta; Deutschland
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 140 x 50 mm / 10.2 x 5.5 x 2 inch
Notes UKW: 87,5 - 104 MHz
KW: 5880 - 10200 kHz
MW: 513 - 1620 kHz
LW: 147 - 350 kHz
Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
External source of data Erb
Source of data Katalog RFP 1973
Mentioned in -- Original-techn. papers.
