Stereo-Box 3820 W

Stereo-Box 3820 W; Loewe-Opta; (ID = 608172) Ampl/Mixer
Stereo-Box 3820 W; Loewe-Opta; (ID = 696004) Ampl/Mixer Stereo-Box 3820 W; Loewe-Opta; (ID = 696008) Ampl/Mixer
Stereo-Box 3820 W; Loewe-Opta; (ID = 569047) Ampl/Mixer Stereo-Box 3820 W; Loewe-Opta; (ID = 696006) Ampl/Mixer
Stereo-Box 3820 W; Loewe-Opta; (ID = 696009) Ampl/Mixer
Use red slider bar for more.
Stereo-Box 3820 W; Loewe-Opta; (ID = 696004) Ampl/Mixer
Loewe-Opta;: Stereo-Box 3820 W [Ampl/Mixer] ID = 696004 624x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo-Box 3820 W, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1958 Category: Audio Amplifier or -mixer
Valves / Tubes 1: ECL82
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Stereo-Box 3820 W - Loewe-Opta; Deutschland
Material Wooden case
Dimensions (WHD) 420 x 705 x 350 mm / 16.5 x 27.8 x 13.8 inch
Notes Zusatzbox mit Verstärker & Plattenwechsler zur NF-Stereowiedergabe an Monoradios. Plattenwechsler: Perpetuum Ebner, Rex A / Stereo. Der linke und der rechte Kanal können mittels eines Schalters vertauscht werden, je demnach, wo die Box in Bezug auf das Radiogerät aufgestellt wird.
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Price in first year of sale 349.00 DM
Literature/Schematics (1) Funkschau 1958

Model page created by Hartmut Daniels † 22.11.16. See "Data change" for further contributors.
