For model T304 54210, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1975/1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 4: BF314 BF254 TBA570 AA119 AA119 AC187 AC188 Si-Br-Gl
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: T304 54210 - Loewe-Opta; Deutschland
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 140 x 57 mm / 10.2 x 5.5 x 2.2 inch
Notes

Loewe Opta Kofferempfänger T304. Gehäuse: nussbaumfarben, schwarz oder rot.

UKW: 87,5 - 104 MHz
KW: 5880 - 10200 kHz (49 m - 31 m Band)
MW: 513 - 1620 kHz
LW: 147 - 350 kHz

Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Collectors' prices
Source of data Handbuch VDRG 1975/1976
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
