Trianon 2696

Trianon 2696; Loewe-Opta; (ID = 325515) TV Radio

Trianon 2696; Loewe-Opta; (ID = 325516) TV Radio
Use red slider bar for more.
Trianon 2696; Loewe-Opta; (ID = 325515) TV Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1961/1962 Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details Changer (Record changer); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Trianon 2696 - Loewe-Opta; Deutschland
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 1230 x 930 x 490 mm / 48.4 x 36.6 x 19.3 inch
Notes Fernseh-Chassis = Optimat 696;
Rundfunk-Chassis = 6768;
Phono-Chassis = Perpetuum-Ebner PE66.
Net weight (2.2 lb = 1 kg) 82 kg / 180 lb 9.9 oz (180.617 lb)
Price in first year of sale 2'198.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1961/62

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
