Gloria GW281

Gloria GW281; Lumophon, Bruckner & (ID = 8979) Radio

Gloria GW281; Lumophon, Bruckner & (ID = 1577558) Radio
Gloria GW281; Lumophon, Bruckner & (ID = 12866) Radio Gloria GW281; Lumophon, Bruckner & (ID = 58912) Radio
Gloria GW281; Lumophon, Bruckner & (ID = 397526) Radio Gloria GW281; Lumophon, Bruckner & (ID = 397524) Radio
Gloria GW281; Lumophon, Bruckner & (ID = 90450) Radio Gloria GW281; Lumophon, Bruckner & (ID = 397523) Radio
Gloria GW281; Lumophon, Bruckner & (ID = 397527) Radio Gloria GW281; Lumophon, Bruckner & (ID = 619805) Radio
Gloria GW281; Lumophon, Bruckner & (ID = 619806) Radio Gloria GW281; Lumophon, Bruckner & (ID = 619807) Radio
Use red slider bar for more.
Gloria GW281; Lumophon, Bruckner & (ID = 12866) Radio
Lumophon, Bruckner &: Gloria GW281 [Radio] ID = 12866 857x569
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gloria GW281, Lumophon, Bruckner & Stark, Nürnberg

Country:  Germany
Manufacturer / Brand:  Lumophon, Bruckner & Stark, Nürnberg
Brand

Lumeta
Year: 1948–1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: RV12P2000 RV12P2000
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Gloria GW281 - Lumophon, Bruckner & Stark,
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 235 x 155 x 130 mm / 9.3 x 6.1 x 5.1 inch
Notes [572]
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 125.00 DM
Collectors' prices
Source of data Illustrierter Rundfunk Kat. 1949 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange-Nowisch


All listed radios etc. from Lumophon, Bruckner & Stark, Nürnberg
Here you find 296 models, 244 with images and 197 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
