• Country
• Finland

• Manufacturer / Brand
• Luxor, Helsinki - see also Sweden

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 303191

• • alternative name: Iskumetalli Oy

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH81 EBF89 ECC82 EL84 EM84

• Number of Transistors
• 2

• Semiconductors
• AF106 AF125 OA90 BA110 AA113 AA113 B250C100

• Main principle
• Superheterodyne (common); ZF/IF 462/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• from Radiomuseum.org
• Model: Rififi 4594W - Luxor, Helsinki - see also

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 575 x 175 x 200 mm / 22.6 x 6.9 x 7.9 inch

• Notes

• Loudspeaker 5X7"

• Author
• Model page created by a member from FIN. See "Data change" for further contributors.
