• Country
• Italy

• Manufacturer / Brand
• Magnadyne Radio; Torino

• Year
• 1951 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103749

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCH42 12BA6 12AT6 50B5 EM34 35R2

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: A14 - Magnadyne Radio; Torino

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 510 x 250 x 175 mm / 20.1 x 9.8 x 6.9 inch

• Notes
• Mobile in legno, maschera frontale in bachelite. Gamme d'onda: 2 medie e 2 corte.
  Wooden case, with bakelite front panel. Wave bands: 2x BC, 2x SW.

• Mentioned in
• - - Data from my own collection

• Author
• Model page created by Paolo De Pasqual. See "Data change" for further contributors.
