MD6112

MD6112; Magnadyne Radio; (ID = 1426140) Radio

MD6112; Magnadyne Radio; (ID = 1426141) Radio
MD6112; Magnadyne Radio; (ID = 1439605) Radio MD6112; Magnadyne Radio; (ID = 1439583) Radio
MD6112; Magnadyne Radio; (ID = 1439585) Radio MD6112; Magnadyne Radio; (ID = 1439587) Radio
MD6112; Magnadyne Radio; (ID = 1439589) Radio MD6112; Magnadyne Radio; (ID = 1439592) Radio
MD6112; Magnadyne Radio; (ID = 1439597) Radio MD6112; Magnadyne Radio; (ID = 1439611) Radio
MD6112; Magnadyne Radio; (ID = 1439612) Radio MD6112; Magnadyne Radio; (ID = 1439613) Radio
Use red slider bar for more.
MD6112; Magnadyne Radio; (ID = 1439605) Radio
Magnadyne Radio;: MD6112 [Radio] ID = 1439605 640x648
Select picture or schematic to display from thumbnails on the right and click for download.
For model MD6112, Magnadyne Radio; Torino

Country:  Italy
Manufacturer / Brand:  Magnadyne Radio; Torino
Year: 1961 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6T26 6E4_Magnadyne 6P1_Magnadyne 16TP8 16TP8 6P6_Magnadyne
Semiconductors (the count is only for transistors) OA79 OA79 OA79 unknown_diode SD-1A
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-230 Volt
Loudspeaker 2 Loudspeakers
Power out 4 W (unknown quality)
from Radiomuseum.org Model: MD6112 - Magnadyne Radio; Torino
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes

Gamma FM provvista di C.A.F.; A.F.C. on the FM band.

Prodotta anche con altri marchi come EP-1112, VI-3112, KE-4112 e NV-9112 (v. Magnadyne Radio; Torino).

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Magnadyne Radio; Torino
Here you find 333 models, 250 with images and 237 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
