• Year
  • 1950 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 243438

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 24
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.25 inch = 18.4 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: CT-219 B - Magnavox Co., Commercial
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • TV-Receiver 12" Picture Tube.

    Channels 2 thru 13.

    Tube V1 alternative 6J6, V2 alternative 6J6, V3 alternative 6J6 or 6AB4
    RF Tuner V601, V602, V603 3 times 6J6.
