I-Connex Docking Station AH 93 IC

Majestic, New Majestic S.p.a.; Crema, CR

Data
Forum
Pictures
Collections

  • Year
  • 2007
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 291311

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • FM Broadcast Band Only
  • Details
  • Other Recorder/Player
  • Power type and voltage
  • Powered by external power supply or a main unit. / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • Power out
  • 4 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: I-Connex Docking Station AH 93 IC - Majestic, New Majestic S.p.a.;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 135 x 143 x 155 mm / 5.3 x 5.6 x 6.1 inch
  • Notes

  • MAJESTIC I-CONNEX mod. AH-93 IC - Docking station per ipod (con 7 adattatori inclusi) - Ingresso ausiliare line-in (possibilità di collegamento lettori MP3) - radio FM PLL con 20 preselezioni - equalizzatore a cinque bande - Display LCD multifunzione - Funzione timer per lo spegnimento automatico - Sveglia con allarme personalizzato (con radio/con ipod/con buzzer) - Funzione ricarica per ipod - Funzione snooze - Telecomando in dotazione – Adattatore AC/DC 230v/50hz – 12v/1Amp. - controllo volume - tasti clock/func/sleep/repeat/memory/play-pause/skip/standby - frequenza FM: 87,5/108 Mhz -consumo 12 watt.

    Made in China.

  • Net weight (2.2 lb = 1 kg)
  • 1.330 kg / 2 lb 14.9 oz (2.93 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
