Multiband BL RT 178

Majestic, New Majestic S.p.a.; Crema, CR

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 291354

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Storage and/or dry batteries / 2 x 1,5 AA Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Multiband BL RT 178 - Majestic, New Majestic S.p.a.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 148 x 85 x 32 mm / 5.8 x 3.3 x 1.3 inch
  • Notes

  • MAJESTIC Multiband BL mod. RT178 Millenium Tecnologies - frequency range: MW 525/1605 kHz, FM: 87,5/108 MHz, LW: 146/281 kHz, SW1: 4.00/5.50 MHz, SW2: 5.90/6.10 MHz, SW3: 7.10/7.30 MHz, SW4: 9.50/9.80 MHz, SW5: 11.65/11.95 MHz, SW6: 13.50/13.80 MHz, SW7: 15.10/15.50 MHz, SW8: 17.40/18.30 MHz, SW9: 21.45/23.70 MHz, volume control, external telescope atenna, internal ferrite antenna, red LED light of receiving, headphone output, 3V jack external power supply, transport handle..

  • Net weight (2.2 lb = 1 kg)
  • 0.350 kg / 0 lb 12.3 oz (0.771 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
