Compact Disc Recorder CDR-1 Professional 74CDR1 /01G

Compact Disc Recorder CDR-1 Professional 74CDR1 /01G; Marantz Sound United (ID = 2451342) R-Player Compact Disc Recorder CDR-1 Professional 74CDR1 /01G; Marantz Sound United (ID = 2451343) R-Player
Compact Disc Recorder CDR-1 Professional 74CDR1 /01G; Marantz Sound United (ID = 2451344) R-Player
Use red slider bar for more.
Compact Disc Recorder CDR-1 Professional 74CDR1 /01G; Marantz Sound United (ID = 2451342) R-Player
Marantz Sound United: Compact Disc Recorder CDR-1 Professional 74CDR1 /01G [R-Player] ID = 2451342 1024x300
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Disc Recorder CDR-1 Professional 74CDR1 /01G, Marantz (Sound United LLC); Vista, CA:
Sold on archiwum.allegro.pl item_7545873237

Country:  United States of America (USA)
Manufacturer / Brand:  Marantz (Sound United LLC); Vista, CA
Year: 1991 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact Disc Recorder CDR-1 Professional 74CDR1 /01G - Marantz Sound United LLC;
Material Metal case
Shape Rack
Dimensions (WHD) 420 x 121 x 330 mm / 16.5 x 4.8 x 13 inch
Notes

A professional hi-fi stereo compact disc recorder/player housed in a champagne gold metal cabinet. Optional rack handles. Supplied with a remote control, also with phono sockets for Philips RC5 interface protocol. With jack for headphones.

Connections
Analogue Outputs
  Analogue Unbalanced Out (RCA)
  Analogue Balanced Out (XLR)
Digital Outputs with On/Off switch
  Digital Out Optical
  Digital Out Electrical (Coaxial)
Analogue Inputs
  Microphone (Left and Right ¼ inch jacks)
  Analogue Balanced In (XLR)
  Analogue Unbalanced In (RCA)
Digital Inputs with Select switch
  Digital In Optical
  Digital In Electrical (Coaxial)

Specification (Playback)
Frequency response:20Hz to 20kHz
Dynamic range:min. 88dB 20Hz to 20kHz
Signal to Noise Ratio:95dB (A-Wtg)
Channel Separation:min. 88dB 20Hz to 20kHz
Line output:2V rms ±1.5dB(unbalanced),
3V rms ±0.1dB (balanced)
Net weight (2.2 lb = 1 kg) 9.9 kg / 21 lb 12.9 oz (21.806 lb)
Price in first year of sale 3'519.00 £
Mentioned in Reviewed by Music Technology UK April 1992
Literature/Schematics (1) - - Manufacturers Literature (Marantz CDR1 Service Manual dated 1991)

Model page created by Howard Craven. See "Data change" for further contributors.
