Integrated Amplifier PM4400

Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258116) Ampl/Mixer Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258117) Ampl/Mixer
Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258118) Ampl/Mixer Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258119) Ampl/Mixer
Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258120) Ampl/Mixer
Use red slider bar for more.
Integrated Amplifier PM4400; Marantz Japan Inc; (ID = 2258116) Ampl/Mixer
Marantz Japan Inc;: Integrated Amplifier PM4400 [Ampl/Mixer] ID = 2258116 1200x360
Select picture or schematic to display from thumbnails on the right and click for download.
For model Integrated Amplifier PM4400, Marantz Japan Inc; Sagamihara

Country:  Japan
Manufacturer / Brand:  Marantz Japan Inc; Sagamihara
Year: 2003 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 100; 230 Volt
Loudspeaker - This model requires external speaker(s).
Power out 60 W (unknown quality)
from Radiomuseum.org Model: Integrated Amplifier PM4400 - Marantz Japan Inc; Sagamihara
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 440 x 116 x 343 mm / 17.3 x 4.6 x 13.5 inch
Notes

Stereo Integrated Amplifier with RC4200PM remote control.

  • Input jacks for MM Phono, CD, Tuner, AUX/DVD, and CDR.
  • Input/output jacks for MD/Tape.
  • Terminals for two pairs of loudspeakers.
  • Controls for input selection, motorised volume, balance, bass and treble.
  • Switches for tone defeat, loudness, speakers 1 and 2, record selector.
  • Indicators for standby and muting.
  • Headphone jack.

Power Output:

  • 30/40 watts RMS (40Hz - 20kHz)  into 8ohms/4ohms
  • 35/45 watts DIN into 8ohms

Power variations:

  • F1N / F1B    100 volts 50/60Hz AC
  • N1B / N1G   230 volts 60Hz AC









Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Howard Craven. See "Data change" for further contributors.
