• Country
• United States of America (USA)

• Manufacturer / Brand
• Marantz (Sound United LLC); Vista, CA

• Year
• 1959–1962

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 171114

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BH6 6BH6 6CG7 6CG7 EL34 or 6CA7 EL34 or 6CA7 EL34 or 6CA7 EL34 or 6CA7

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 60 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Power Amplifier Model 8 - Marantz Sound United LLC;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 13.5 x 7.25 x 10.5 inch / 343 x 184 x 267 mm

• Notes

• A 2 x 30 watt stereo Power Amplifier with bias meter and power supply outlet for Preamplifier. Price $237, optional gold finish perforated grille $9.

  Power Requirements
  117 (105-125) volts AC 50/60Hz

  Power consumption: 170-230 Watts max.

• Price in first year of sale
• 237.00 $

• Mentioned in
• -- Original prospect or advert (Marantz model 8 Dual-Thirty Stereophonic Power Amplifier brochure)

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
