Portable Professional Cassette Recorder PMD430

Marantz (Sound United LLC); Vista, CA

  • Year
  • 1984 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 278317

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / 3 x 1,5 / 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Portable Professional Cassette Recorder PMD430 - Marantz Sound United LLC;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 227 x 50 x 165 mm / 8.9 x 2 x 6.5 inch
  • Notes
  • Stereo, total 3 Tonköpfe
    Mikrofoneingang 6,3mm
    1 Bandgeschwindigkeit (4,76cm/s)
    Autostop/Autoplay bei Bandzähler 999 möglich

  • Net weight (2.2 lb = 1 kg)
  • 1.3 kg / 2 lb 13.8 oz (2.863 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by a member from CH. See "Data change" for further contributors.
