Stereophonic Receiver 2285B

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223767) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223768) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223769) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223770) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223771) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223772) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223773) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223774) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223775) Radio

Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223776) Radio
Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604246) Radio Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604243) Radio
Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604247) Radio Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604248) Radio
Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604244) Radio Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604245) Radio
Stereophonic Receiver 2285B; Marantz Sound United (ID = 1814183) Radio Stereophonic Receiver 2285B; Marantz Sound United (ID = 2223479) Radio
Use red slider bar for more.
Stereophonic Receiver 2285B; Marantz Sound United (ID = 2604246) Radio
Marantz Sound United: Stereophonic Receiver 2285B [Radio] ID = 2604246 1400x882
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereophonic Receiver 2285B, Marantz (Sound United LLC); Vista, CA

Country:  United States of America (USA)
Manufacturer / Brand:  Marantz (Sound United LLC); Vista, CA
Year: 1977–1980 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 170 W (unknown quality)
from Radiomuseum.org Model: Stereophonic Receiver 2285B - Marantz Sound United LLC;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 17.25 x 5.5 x 14.25 inch / 438 x 140 x 362 mm
Notes AM/FM Stereo Receiver.
85 watts per channel, both channels driven at 8 ohms from 20 to 20000 Hz with 0,05% THD.
Bass-, Treble- and Loudness-Control, Low- and High-Filter.
FM 87,5-108 MHz, AM 525-1605kHz.
Optional: Wood Case Marantz WC-122, Marantz DLB1 Dolby FM Decoder (US Models only!)
Net weight (2.2 lb = 1 kg) 37 lb 4 oz (37.25 lb) / 16.912 kg
Price in first year of sale 670.00 $
Source of data -- Collector info (Sammler)

Model page created by Franz Scharner. See "Data change" for further contributors.
