Stereophonic Receiver nineteen (19)
Marantz (Sound United LLC); Vista, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Marantz (Sound United LLC); Vista, CA
- Year
- 1971 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 225881
- Number of Tubes
- 1
- Valves / Tubes
- D3-11GJ
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet with RF-stage
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 100 W (150 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stereophonic Receiver nineteen - Marantz Sound United LLC;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 19 x 6.5 x 16 inch / 483 x 165 x 406 mm
- Notes
-
CRT tuning indicator (oscilloscope).
- Price in first year of sale
- 6,500.00 DM
- Mentioned in
- USA: Audio (Magazine), March 1971, p. 60
- Author
- Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
