Leistungs-Meßverstärker NVL-156

Marchetti, Dipl. Ing. Peter, Labor für HF- und NF-Technik; Wien

Data
Forum
Pictures
Collections

  • Year
  • 1960 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 273037

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 20 W (30 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Leistungs-Meßverstärker NVL-156 - Marchetti, Dipl. Ing. Peter,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 533 x 270 x 330 mm / 21 x 10.6 x 13 inch
  • Notes

  • Röhren Leistungs-Meßverstärker

    Klirrfaktor bei P = 20W <0,2%
    Klirrfaktor bei P = 30W <1%
    20Hz ... 40kHz

    Aufwändiger Ausgangsübertrager
    Ventilatorgekühlte Endstufe

  • Author
  • Model page created by Christian Auer. See "Data change" for further contributors.
