Bass Guitar Amplifier MB450H

Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588354) Ampl/Mixer Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588355) Ampl/Mixer
Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588356) Ampl/Mixer Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588357) Ampl/Mixer
Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588358) Ampl/Mixer Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588359) Ampl/Mixer
Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588360) Ampl/Mixer Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588366) Ampl/Mixer
Use red slider bar for more.
Bass Guitar Amplifier MB450H; Marshall, Jim, (ID = 1588354) Ampl/Mixer
Marshall, Jim,: Bass Guitar Amplifier MB450H [Ampl/Mixer] ID = 1588354 895x500
Select picture or schematic to display from thumbnails on the right and click for download.
For model Bass Guitar Amplifier MB450H, Marshall, Jim, (Products) Ltd.; Hanwell

Country:  Great Britain (UK)
Manufacturer / Brand:  Marshall, Jim, (Products) Ltd.; Hanwell
Year: 2005 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 1: ECC83
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Guitar Amplifier
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 450 W (undistorted)
from Radiomuseum.org Model: Bass Guitar Amplifier MB450H - Marshall, Jim, Products Ltd.;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 220 x 235 mm / 24.8 x 8.7 x 9.3 inch
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)

Model page created by Bartosz Szwed. See "Data change" for further contributors.



All listed radios etc. from Marshall, Jim, (Products) Ltd.; Hanwell
Here you find 14 models, 14 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
