AS-350

AS-350; Panasonic, (ID = 2039316) Radio
AS-350; Panasonic, (ID = 234519) Radio AS-350; Panasonic, (ID = 232985) Radio
AS-350; Panasonic, (ID = 234518) Radio
Use red slider bar for more.
AS-350; Panasonic, (ID = 234519) Radio
Panasonic,: AS-350 [Radio] ID = 234519 621x383
Select picture or schematic to display from thumbnails on the right and click for download.
For model AS-350, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Dank an H. Yanai, Japan.

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6W-C5 UZ-6D6 6Z-DH3A UZ-42 KX-80
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 100 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 2.8 W (unknown quality)
from Radiomuseum.org Model: AS-350 - Panasonic, Matsushita,
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Eines der ersten japanischen Heim-Radios mit KW-Bereich.
External source of data H. Yanai

Model page created by Berthold Bosch † 13.2.19. See "Data change" for further contributors.
