Univers (Volt/Ampere-Meter) 10-47

Maurits Andersen Instrumentfabrik, Kopenhavn

  • Year
  • 1947 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 136681
    • alternative name: MA Instrumenfabrik

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 4,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Univers 10-47 - Maurits Andersen
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 268 x 125 x 195 mm / 10.6 x 4.9 x 7.7 inch
  • Notes
  • Universal-Meter; Univers 10-47.
    Ranges:
    Voltage AC/DC: 1,5, 3, 15, 75, 300, 750 V.
    Current AC/DC: 1,5, 15, 75, 300, 750 mA, 3 A.
    Resistance: 100 Ω, 1 kΩ, 10 kΩ.
  • Net weight (2.2 lb = 1 kg)
  • 2.9 kg / 6 lb 6.2 oz (6.388 lb)
  • Source of data
  • - - Data from my own collection
