A-116A

A-116A; McIntosh Audio (ID = 1277804) Ampl/Mixer

A-116A; McIntosh Audio (ID = 1277806) Ampl/Mixer
A-116A; McIntosh Audio (ID = 445442) Ampl/Mixer A-116A; McIntosh Audio (ID = 445447) Ampl/Mixer
A-116A; McIntosh Audio (ID = 445448) Ampl/Mixer A-116A; McIntosh Audio (ID = 445450) Ampl/Mixer
A-116A; McIntosh Audio (ID = 445451) Ampl/Mixer A-116A; McIntosh Audio (ID = 445452) Ampl/Mixer
A-116A; McIntosh Audio (ID = 1389868) Ampl/Mixer
Use red slider bar for more.
A-116A; McIntosh Audio (ID = 445442) Ampl/Mixer
McIntosh Audio: A-116A [Ampl/Mixer] ID = 445442 544x240
Select picture or schematic to display from thumbnails on the right and click for download.
For model A-116A, McIntosh Audio Company; Binghamton, NY:
a pair of amps -- Bild aus ebay, mit Erlaubnis des Verkäufers em85

Country:  United States of America (USA)
Manufacturer / Brand:  McIntosh Audio Company; Binghamton, NY
Year: 1950 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 6: 12AX7 12BH7 12BH7 6BG6G 6BG6G 5U4G
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: A-116A - McIntosh Audio Company;
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 12 x 8 x 8.5 inch / 305 x 203 x 216 mm
Notes power amp, mono; with power supply for preamp C-104.
Net weight (2.2 lb = 1 kg) 33 lb (33 lb 0 oz) / 14.982 kg
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.



All listed radios etc. from McIntosh Audio Company; Binghamton, NY
Here you find 76 models, 69 with images and 34 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
