• Country
• United States of America (USA)

• Manufacturer / Brand
• McIntosh Audio Company; Binghamton, NY

• Year
• 1980–1985

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 136712

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superhet with RF-stage

• Wave bands
• FM Broadcast Band Only

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Digital FM Tuner MR80 - McIntosh Audio Company;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 406 x 138 x 330 mm / 16 x 5.4 x 13 inch

• Notes
• Tuner with 4 presets and LED frequency display; with outputs for scope.

• Net weight (2.2 lb = 1 kg)
• 12.7 kg / 27 lb 15.6 oz (27.974 lb)

• Price in first year of sale
• 2,499.00 $

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
