M84A-2 (84A-2)

M84A-2 ; Mediator; La Chaux- (ID = 2033289) Radio

M84A-2 ; Mediator; La Chaux- (ID = 2033290) Radio
M84A-2 ; Mediator; La Chaux- (ID = 694412) Radio M84A-2 ; Mediator; La Chaux- (ID = 694413) Radio
M84A-2 ; Mediator; La Chaux- (ID = 694414) Radio M84A-2 ; Mediator; La Chaux- (ID = 711433) Radio
Use red slider bar for more.
M84A-2 ; Mediator; La Chaux- (ID = 694412) Radio
Mediator; La Chaux-: M84A-2 [Radio] ID = 694412 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model M84A-2 (84A-2), Mediator; La Chaux-de-Fonds

Country:  Switzerland
Manufacturer / Brand:  Mediator; La Chaux-de-Fonds
Year: 1943–1945 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH21 UCH21 UBL21 UY1(N)
Main principle Super-Heterodyne (Super in general); ZF/IF 473 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 22 cm = 8.7 inch
Power out
from Radiomuseum.org Model: M84A-2 - Mediator; La Chaux-de-Fonds
Material Bakelite case
Dimensions (WHD) 420 x 280 x 180 mm / 16.5 x 11 x 7.1 inch
Notes Linearskala oben.
Siehe auch Modell M84A-3 mit zusätzlichem LW-Bereich.
Price in first year of sale 350.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die Tungsram-Tabellen führen das Modell auf.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
