Koffer-Radio MD6556AB
Mediator; La Chaux-de-Fonds
- Country
- Switzerland
- Manufacturer / Brand
- Mediator; La Chaux-de-Fonds
- Year
- 1954/1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 12435
Frontansicht
Innenansicht komplett
Rückansicht
Das "magische Auge"
Frontansicht
Die Rahmenantenne im Deckel
Ansicht des Bodendeckels aus Holz
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 452 kHz
- Power type and voltage
- Line / Batteries (any type)
- Loudspeaker
- Presumably Dynamic Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: Koffer-Radio MD6556AB - Mediator; La Chaux-de-Fonds
- Notes
- Tr.Gl. = 220B100
- Price in first year of sale
- 298.00 SFr
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Other Models
-
Here you find 370 models, 324 with images and 225 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Mediator; La Chaux-de-Fonds
Collections
The model Koffer-Radio is part of the collections of the following members.
Forum contributions about this model: Mediator; La Chaux-: Koffer-Radio MD6556AB
Threads: 1 | Posts: 2
Gemäss Typenschild wurde dieses Radio in Holland gefertigt, aber für den Schweizer Markt....
Wellenlängen MW-LW-KW
Gehäuse aus Holz, mit Kunststoff-Folie überzogen, Bodenplatte Holz.
Mario Monego, 23.Oct.09
