For model MD2523U / 00M, Mediator; La Chaux-de-Fonds

Country:  Switzerland
Manufacturer / Brand:  Mediator; La Chaux-de-Fonds
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCC85 UF89 UCH81 UABC80 UM80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage AC/DC-set / 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: MD2523U / 00M - Mediator; La Chaux-de-Fonds
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 340 x 200 x 150 mm / 13.4 x 7.9 x 5.9 inch
Notes Den Mediator MD2523U gibt es in verschiedenen Unterausführungen, z.B. als / 00.M.

Model page created by Gian-Fausto Balestra. See "Data change" for further contributors.
