- Country
- Germany
- Manufacturer / Brand
- Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Year
- 1968/1969
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 27443
ebay
ebay
Funkschau 1968 Heft 16
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 37
- Semiconductors
- BF200 BF224 BF184 BF123 BC108 AC153 BC178 BC109 BF245 2N3708 BC107 BC177 AD166 BA110 ZF10 AA119 B40C2200 B30C450
- Main principle
- Superhet with RF-stage; ZF/IF 10700 kHz
- Tuned circuits
- 15 FM circuit(s)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 130; 220; 230; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 20 W (30 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: HiFi 485 - Metz Transformatoren- und
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 460 x 145 x 340 mm / 18.1 x 5.7 x 13.4 inch
- Notes
-
Metz HiFi 485
Metz bezeichnet das Gerät als Hi-Fi-Verstärker mit UKW-Empfangsteil
Vollstereo, NF-Verstärker mit zwei Endstufen je 10 W (Sinus) bzw 15 Watt Musikleistung, Empfindlichkeit des UKW Empfängers 1,0 µV 26 dB Mono
Jeder Halbleitertyp nur einmal gelistet.
Technisch identisch mit Metz HiFi 495.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- External source of data
- erb
- Source of data
- Handbuch VDRG 1968/1969
- Mentioned in
- -- Original-techn. papers. (Serviceanleitung)
- Other Models
-
Here you find 583 models, 457 with images and 302 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
