- Country
- Germany
- Manufacturer / Brand
- Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Year
- 1968–1971
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 27529
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 17
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 944 - Metz Transformatoren- und
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 395 x 172 x 345 mm / 15.6 x 6.8 x 13.6 inch
- Notes
- Vierspur; 9,5 cm/s; Spulen-Ø 18 cm.
Einige Transistortypen mehrfach vorhanden.
- Net weight (2.2 lb = 1 kg)
- 8.5 kg / 18 lb 11.6 oz (18.722 lb)
- Price in first year of sale
- 419.00 DM
- External source of data
- erb
- Source of data
- Handbuch VDRG 1968/1969
- Mentioned in
- Handbuch VDRG 1970/1971
