Stereo Graphic Equalizer EX-4964
Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Country
- Germany
- Manufacturer / Brand
- Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Year
- 1981–1983
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 177697
Bild aus Metz Service Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Graphic Equalizer EX-4964 - Metz Transformatoren- und
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 450 x 60 x 340 mm / 17.7 x 2.4 x 13.4 inch
- Notes
- 11 IC Metz Stereo Equalizer EX 4964; 18 Pegelregler für je 12 dB-Anhebung oder Absenkung (jeweils im Oktaven-Abstand, Durchgangsverstärkung (Pegelregler in Mittelstellung) 6 dB.
- Literature/Schematics (1)
- Original Metz Service Unterlagen
- Author
- Model page created by Josef Pilz. See "Data change" for further contributors.
