Chassis 16-35

Chassis 16-35; Midwest Radio Co., (ID = 526172) Radio

Chassis 16-35; Midwest Radio Co., (ID = 526173) Radio
Use red slider bar for more.
Chassis 16-35; Midwest Radio Co., (ID = 526172) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Midwest Radio Co., The, (Miraco); Cincinnati, OH
Brand

Miraco
Year: 1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 16: 6D6 6D6 6D6 6D6 6D6 76 76 76 6B7 6C6 2A5 45 45 45 45 5Z3
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 10 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Chassis 16-35 - Midwest Radio Co., The, Miraco
Material Metal case
Shape Chassis only or for «building in»
Notes choice of cabinets. 2 Edyn speakers. Used in console models A-16(1935), B16(1935), D-16(1935), K-16(1935), PR-16(1935).
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 6 = 1935 and before
