Fleetwood Ch= Regal 1936

Fleetwood Ch= Regal 1936; Midwest Radio Co., (ID = 526524) Radio

Fleetwood Ch= Regal 1936; Midwest Radio Co., (ID = 526525) Radio

Fleetwood Ch= Regal 1936; Midwest Radio Co., (ID = 526526) Radio
Fleetwood Ch= Regal 1936; Midwest Radio Co., (ID = 712070) Radio
Use red slider bar for more.
Fleetwood Ch= Regal 1936; Midwest Radio Co., (ID = 712070) Radio
Midwest Radio Co.,: Fleetwood Ch= Regal 1936 [Radio] ID = 712070 469x768
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fleetwood Ch= Regal 1936, Midwest Radio Co., The, (Miraco); Cincinnati, OH:
Image Courtesy of Mark V. Stein for Radiomuseum.org use only.

Country:  United States of America (USA)
Manufacturer / Brand:  Midwest Radio Co., The, (Miraco); Cincinnati, OH
Brand

Miraco
Year: 1937 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 20: 6K7 6C5 6J7 6K7 6H6 6C5 6K7 6K7 6K7 6H6 6L7 6C5 6N6 6N6 6N6 6N6 80 80 5W4 5W4
Semiconductors (the count is only for transistors) 2M2 2M2
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 9 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Fleetwood Ch= Regal 1936 - Midwest Radio Co., The, Miraco
Material Wooden case
Shape Console with any shape - in general
Notes 1 Edyn (bass) and 2 PM (treble) speakers. Dynamic expansion.
Source of data Pre-War Consoles
Circuit diagram reference Rider's Perpetual, Volume 8 = 1937 and before

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from Midwest Radio Co., The, (Miraco); Cincinnati, OH
Here you find 316 models, 177 with images and 213 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
