Kondensatormikrofon-Kapsel UM70

Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 240396) Microphone/PU Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 332868) Microphone/PU
Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 332871) Microphone/PU Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 240397) Microphone/PU
Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 332869) Microphone/PU Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 332872) Microphone/PU
Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 580765) Microphone/PU Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 580766) Microphone/PU
Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 580767) Microphone/PU Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 580768) Microphone/PU
Use red slider bar for more.
Kondensatormikrofon-Kapsel UM70; Mikrofontechnik (ID = 240396) Microphone/PU
Mikrofontechnik: Kondensatormikrofon-Kapsel UM70 [Microphone/PU] ID = 240396 800x570
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kondensatormikrofon-Kapsel UM70, Mikrofontechnik Gefell, VEB; Gefell (Ostd.):
mit freundlicher schriftlicher Genehmigung von Musikinstrumente Design Berlin - danke -

Country:  Germany
Manufacturer / Brand:  Mikrofontechnik Gefell, VEB; Gefell (Ostd.)
alternative name

Microtech Gefell GmbH
Year: 1970 ?? Category: Microphone or Pick-up element
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Kondensatormikrofon-Kapsel UM70 - Mikrofontechnik Gefell, VEB;
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 42 x 42 x 82 mm / 1.7 x 1.7 x 3.2 inch
Notes Kondensatormikrofonkapsel UM70; Richtcharakteristik umschaltbar: Niere, Kugel, Acht; goldbedampfte Großmembran, Übertragungsbereich: 30...18000 Hz. Zu betreiben mit passendem Mikrofonvorverstärker/Impedanzwandler MV690, MV691, MV692 und geeignetem Netzanschlußgerät z.B. N691.
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 217.00 DM
Mentioned in -- Original-techn. papers.

Model page created by Wolfgang Lill. See "Data change" for further contributors.
