Nevada 465/3

Nevada 465/3; Minerva Ital-Minerva (ID = 952513) Radio
Nevada 465/3; Minerva Ital-Minerva (ID = 2277468) Radio Nevada 465/3; Minerva Ital-Minerva (ID = 2352604) Radio
Nevada 465/3; Minerva Ital-Minerva (ID = 2352601) Radio Nevada 465/3; Minerva Ital-Minerva (ID = 1730096) Radio
Nevada 465/3; Minerva Ital-Minerva (ID = 2352600) Radio Nevada 465/3; Minerva Ital-Minerva (ID = 2352606) Radio
Nevada 465/3; Minerva Ital-Minerva (ID = 2352607) Radio Nevada 465/3; Minerva Ital-Minerva (ID = 1730060) Radio
Nevada 465/3; Minerva Ital-Minerva (ID = 1729078) Radio Nevada 465/3; Minerva Ital-Minerva (ID = 1729049) Radio
Use red slider bar for more.
Nevada 465/3; Minerva Ital-Minerva (ID = 2277468) Radio
Minerva Ital-Minerva: Nevada 465/3 [Radio] ID = 2277468 1400x1066
Select picture or schematic to display from thumbnails on the right and click for download.
For model Nevada 465/3, Minerva (Ital-Minerva); Milano

Country:  Italy
Manufacturer / Brand:  Minerva (Ital-Minerva); Milano
alternative name

Cozzi Luigi Dell'Aquila
Year: 1946 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH4 EF9 EBF2 EL2 6X5
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Nevada 465/3 - Minerva Ital-Minerva; Milano
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 285 x 200 x 150 mm / 11.2 x 7.9 x 5.9 inch
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Minerva (Ital-Minerva); Milano
Here you find 238 models, 192 with images and 131 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
