473/1 EF9 & WE13

473/1; Minerva Ital-Minerva (ID = 205209) Radio

473/1; Minerva Ital-Minerva (ID = 2075970) Radio
473/1; Minerva Ital-Minerva (ID = 652913) Radio 473/1; Minerva Ital-Minerva (ID = 652919) Radio
473/1; Minerva Ital-Minerva (ID = 652914) Radio 473/1; Minerva Ital-Minerva (ID = 652915) Radio
473/1; Minerva Ital-Minerva (ID = 652916) Radio 473/1; Minerva Ital-Minerva (ID = 652917) Radio
473/1; Minerva Ital-Minerva (ID = 652918) Radio 473/1; Minerva Ital-Minerva (ID = 1732335) Radio
Use red slider bar for more.
473/1; Minerva Ital-Minerva (ID = 652913) Radio
Minerva Ital-Minerva: 473/1 [Radio] ID = 652913 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model 473/1 EF9 & WE13, Minerva (Ital-Minerva); Milano

Country:  Italy
Manufacturer / Brand:  Minerva (Ital-Minerva); Milano
alternative name

Cozzi Luigi Dell'Aquila
Year: 1939 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: EF9 WE13 6X5
Main principle TRF without regeneration
Tuned circuits 2 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: 473/1 [EF9 & WE13] - Minerva Ital-Minerva; Milano
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 240 x 175 x 190 mm / 9.4 x 6.9 x 7.5 inch
Notes Due sole stazioni in OM ricevibili, sintonizzate in fabbrica
Mentioned in Bruno Angeletti: Il Manuale del Radio Meccanico Vol 2, pag.483
Literature/Schematics (1) Riparazioni - Scuola Radio Elettra (pag. M55)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
