477/1; Minerva Ital-Minerva (ID = 615265) Radio
Minerva Ital-Minerva: 477/1 [Radio] ID = 615265 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model 477/1, Minerva (Ital-Minerva); Milano

Country:  Italy
Manufacturer / Brand:  Minerva (Ital-Minerva); Milano
alternative name

Cozzi Luigi Dell'Aquila
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECH4 EBF2 EF9 EL3 EM4 6C5G EL3 WE53
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 477/1 - Minerva Ital-Minerva; Milano
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 390 x 300 mm / 24.8 x 15.4 x 11.8 inch
Source of data Guida Pratica Antique Radio V (2003)
Literature/Schematics (1) Riparazioni - Scuola Radio Elettra (pag. M56)

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Minerva (Ital-Minerva); Milano
Here you find 238 models, 192 with images and 131 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
