Cadet W (A)

Cadet W ; Minerva-Radio (ID = 310021) Radio

Cadet W ; Minerva-Radio (ID = 357351) Radio
Cadet W ; Minerva-Radio (ID = 409003) Radio Cadet W ; Minerva-Radio (ID = 409007) Radio
Cadet W ; Minerva-Radio (ID = 409006) Radio Cadet W ; Minerva-Radio (ID = 74135) Radio
Cadet W ; Minerva-Radio (ID = 409004) Radio Cadet W ; Minerva-Radio (ID = 409005) Radio
Cadet W ; Minerva-Radio (ID = 409008) Radio Cadet W ; Minerva-Radio (ID = 1526936) Radio
Use red slider bar for more.
Cadet W ; Minerva-Radio (ID = 409003) Radio
Minerva-Radio: Cadet W [Radio] ID = 409003 480x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cadet W (A), Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien:
Minerva Cadet W

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: RENS1284 or S435N or NCC4 RES964 or P435 or P43 RGN504 or G470 or VG406
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Cadet W - Minerva-Radio Radiola-
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 250 x 320 x 150 mm / 9.8 x 12.6 x 5.9 inch
Notes
Price in first year of sale 189.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange + Schenk


All listed radios etc. from Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Here you find 627 models, 559 with images and 444 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
