Cordless-Home 625; Minerva-Radio (ID = 3375) Radio
Minerva-Radio: Cordless-Home 625 [Radio] ID = 3375 628x500
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cordless-Home 625 ab Nr. 918.901, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien:
Minerva Cordless Home, 625

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF116 AF116 AF116 OC75 AC126 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 461/10700 kHz
Tuned circuits 9 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6x1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Cordless-Home 625 [ab Nr. 918.901] - Minerva-Radio Radiola-
Material Wooden case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 365 x 245 x 140 mm / 14.4 x 9.6 x 5.5 inch
Notes Zusatz-Netzteil, Einbau möglich.
Net weight (2.2 lb = 1 kg) 4.8 kg / 10 lb 9.2 oz (10.573 lb)
Price in first year of sale 1'850.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
Mentioned in RADIOBOTE, Österr. (Heft 31/2011, S.15 ff, Gerätebeschreibung)
