Forte 621L Ab Nr.: 942751

Forte 621L; Minerva-Radio (ID = 6653) Radio

Forte 621L; Minerva-Radio (ID = 1293634) Radio

Forte 621L; Minerva-Radio (ID = 1293635) Radio

Forte 621L; Minerva-Radio (ID = 1293630) Radio
Forte 621L; Minerva-Radio (ID = 2568179) Radio Forte 621L; Minerva-Radio (ID = 2568181) Radio
Forte 621L; Minerva-Radio (ID = 2568180) Radio Forte 621L; Minerva-Radio (ID = 2568182) Radio
Forte 621L; Minerva-Radio (ID = 2568183) Radio Forte 621L; Minerva-Radio (ID = 240125) Radio
Forte 621L; Minerva-Radio (ID = 240127) Radio Forte 621L; Minerva-Radio (ID = 3913) Radio
Forte 621L; Minerva-Radio (ID = 240126) Radio Forte 621L; Minerva-Radio (ID = 2056) Radio
Use red slider bar for more.
Forte 621L; Minerva-Radio (ID = 2568179) Radio
Minerva-Radio: Forte 621L [Radio] ID = 2568179 1400x1150
Select picture or schematic to display from thumbnails on the right and click for download.
For model Forte 621L Ab Nr.: 942751, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien:
Minerva Forte 621L - grau - 981203 - Ursprung: Klaus R. Tiefenbacher

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF116 AF116 AF116 AC126 AC126 AC132 AC127
Main principle Superheterodyne (common); ZF/IF 461/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 6x1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Forte 621L [Ab Nr.: 942751] - Minerva-Radio Radiola-
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 200 x 140 x 70 mm / 7.9 x 5.5 x 2.8 inch
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Price in first year of sale 1'295.00 öS
External source of data E. Erb 3-907007-36-0
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
