Kraftsuper KV35W

Kraftsuper KV35W; Minerva-Radio (ID = 317841) Radio

Kraftsuper KV35W; Minerva-Radio (ID = 8500) Radio

Kraftsuper KV35W; Minerva-Radio (ID = 357800) Radio
Kraftsuper KV35W; Minerva-Radio (ID = 1043691) Radio Kraftsuper KV35W; Minerva-Radio (ID = 1043624) Radio
Kraftsuper KV35W; Minerva-Radio (ID = 1043692) Radio Kraftsuper KV35W; Minerva-Radio (ID = 39385) Radio
Kraftsuper KV35W; Minerva-Radio (ID = 1043022) Radio Kraftsuper KV35W; Minerva-Radio (ID = 1043623) Radio
Kraftsuper KV35W; Minerva-Radio (ID = 1043693) Radio
Use red slider bar for more.
Kraftsuper KV35W; Minerva-Radio (ID = 1043691) Radio
Minerva-Radio: Kraftsuper KV35W [Radio] ID = 1043691 547x460
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kraftsuper KV35W, Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien

Country:  Austria
Manufacturer / Brand:  Minerva-Radio (Radiola-Radioapparate und Bestandteile W. Wohleber & Co) ; Wien
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK1 E447 E446 F443N 1561
Semiconductors (the count is only for transistors) WX6
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Kraftsuper KV35W - Minerva-Radio Radiola-
Material Special material, described in the notes.
Dimensions (WHD) 380 x 270 x 280 mm / 15 x 10.6 x 11 inch
Notes Abstimm-Anzeige mit Instrument, Demodulator-Diode auch WMX12 möglich.
Gehäuse: Holz mit Aluminium kombiniert Gerät kann nur in Verbindung mit dem externen Drosselaggregat (montiert hinter der Schallwand des zugehörigen Lautsprechers) verwendet werden.
Price in first year of sale 600.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange + Schenk
Mentioned in Radio-Amateur Wien (RA, 46), (Österreichischer Radio Amateur, ÖRA) (3507)
