Merano 626/9

Merano 626/9; Minerva Ital-Minerva (ID = 1053989) Radio
Merano 626/9; Minerva Ital-Minerva (ID = 245477) Radio Merano 626/9; Minerva Ital-Minerva (ID = 245478) Radio
Merano 626/9; Minerva Ital-Minerva (ID = 245479) Radio Merano 626/9; Minerva Ital-Minerva (ID = 1926442) Radio
Merano 626/9; Minerva Ital-Minerva (ID = 1926443) Radio Merano 626/9; Minerva Ital-Minerva (ID = 1926444) Radio
Merano 626/9; Minerva Ital-Minerva (ID = 1926445) Radio
Use red slider bar for more.
Merano 626/9; Minerva Ital-Minerva (ID = 245477) Radio
Minerva Ital-Minerva: Merano 626/9 [Radio] ID = 245477 900x547
Select picture or schematic to display from thumbnails on the right and click for download.
For model Merano 626/9, Minerva (Ital-Minerva); Milano

Country:  Italy
Manufacturer / Brand:  Minerva (Ital-Minerva); Milano
alternative name

Cozzi Luigi Dell'Aquila
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 UF89 UABC80 UL84 UY85
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Merano 626/9 - Minerva Ital-Minerva; Milano
Material Plastics (no bakelite or catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 360 x 165 x 130 mm / 14.2 x 6.5 x 5.1 inch
Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Mentioned in Guida Pratica Antique Radio IV (2001)

Model page created by Paolo De Pasqual. See "Data change" for further contributors.
