• Year
  • 1987 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 137940

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220/6x1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 4.8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: RKS 1115 - Minerva-Radio Radiola-
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes
  • Doppel Cassetten Deck; 6 IC`s TA7335P TA7640AP TA7343AP TA7658P TDA2824.

    Paralleltype zum Grundig RR 1110.

  • Mentioned in
  • Original Service Unterlagen
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
