R44

R44; Mivar VAR; Milano (ID = 2512915) Radio R44; Mivar VAR; Milano (ID = 2512917) Radio
R44; Mivar VAR; Milano (ID = 2512916) Radio R44; Mivar VAR; Milano (ID = 2512918) Radio
R44; Mivar VAR; Milano (ID = 2512919) Radio R44; Mivar VAR; Milano (ID = 312723) Radio
Use red slider bar for more.
R44; Mivar VAR; Milano (ID = 2512915) Radio
Mivar VAR; Milano: R44 [Radio] ID = 2512915 1400x748
Select picture or schematic to display from thumbnails on the right and click for download.
For model R44, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 5: BF235 BF235 BF233 BF233 BF233 TAA611
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / 2 x 4,5 / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: R44 - Mivar VAR; Milano
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 165 x 72 mm / 10.2 x 6.5 x 2.8 inch
Notes

4 Diodi, 1 Zener, 1 IC.

FM/ OM/ OM auto. Presa per antenna esterna.

Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
Mentioned in -- Original-techn. papers.

Model page created by Federico Valdameri † 7.2015. See "Data change" for further contributors.
