R46; Mivar VAR; Milano (ID = 1026402) Radio
Mivar VAR; Milano: R46 [Radio] ID = 1026402 933x282
Select picture or schematic to display from thumbnails on the right and click for download.
For model R46, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: BF195 BF195 BF195 BF195 BF195 BC159 BC148 AC188 AC187 BC159 AA119 AA119 AA119 AA119 BZY88
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: R46 - Mivar VAR; Milano
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 630 x 175 x 170 mm / 24.8 x 6.9 x 6.7 inch
Notes

Ponte raddrizzatore B30 C450. Altoparlante: 18 x 12,5 cm. Impedenza 8 Ohm.

  • Regolazione singola per toni bassi ed alti;
  • Consumo 12 W;
  • Presa DIN per ragistratore;
  • Presa Phono.
Price in first year of sale 50'250.00 ITL
Source of data Guida Pratica Antique Radio (1) 1999
Mentioned in -- Schematic
Literature/Schematics (1) Catalogo ANIE (1970-71, p. 78)

Model page created by Pietro Gallia. See "Data change" for further contributors.
