R48-B

R48-B; Mivar VAR; Milano (ID = 1747756) Radio R48-B; Mivar VAR; Milano (ID = 1747745) Radio
R48-B; Mivar VAR; Milano (ID = 1747746) Radio R48-B; Mivar VAR; Milano (ID = 1747747) Radio
R48-B; Mivar VAR; Milano (ID = 1747748) Radio R48-B; Mivar VAR; Milano (ID = 1747749) Radio
R48-B; Mivar VAR; Milano (ID = 1747750) Radio R48-B; Mivar VAR; Milano (ID = 1747751) Radio
R48-B; Mivar VAR; Milano (ID = 1747752) Radio R48-B; Mivar VAR; Milano (ID = 1747753) Radio
Use red slider bar for more.
R48-B; Mivar VAR; Milano (ID = 1747756) Radio
Mivar VAR; Milano: R48-B [Radio] ID = 1747756 733x550
Select picture or schematic to display from thumbnails on the right and click for download.
For model R48-B, Mivar (VAR); Milano

Country:  Italy
Manufacturer / Brand:  Mivar (VAR); Milano
Year: 1970 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 5: BF235 BF235 BF233 BF233 BF233 TAA611 B30C400
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 13 cm = 5.1 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: R48-B - Mivar VAR; Milano
Material Plastics (no bakelite or catalin)
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 305 x 150 x 115 mm / 12 x 5.9 x 4.5 inch
Notes

Uscita per registratore/AUX.
Antenna interna su ferrite per OM e presa esterna per antenna FM.

Net weight (2.2 lb = 1 kg) 0.890 kg / 1 lb 15.4 oz (1.96 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
